Technical advantage
•cover a small area，Simple layout.
•Refined management，System temperature difference≤3℃；whole system charging and discharging ≥88%.
•Critical component and PACK IP67protection，Outdoor cabinetIP55 protection.
•Accurate recording monitoring status and faults，Realize fault early warning and fault location.
•Modular design for convenient transportation and operation and maintenance; Integrated system design, pre-installation and pre-commissioning, reduces on-site commissioning work.
Battery capacity | 280Ah | 314Ah | 320Ah | |
Battery data | Nominal voltage at DC | 832V | ||
Max Charge and Discharge power | 0.5CC/0.5CD | 0.5CC/0.5CD | 0.25CC/0.25CD | |
Battery capacity (BOL) at DC side | 232.9KWh | 261.2KWh | 266.2KWh | |
Performance & safety | Nominal DC Charge and Discharge power | 94% | ||
Cell type | LFP | |||
life span | 20years | |||
fire extinguishing system | Aerosol + Water fire extinguishing system | |||
Temperature control mode | Liquid Cooling | |||
approval standards | UL9540/CE/IEC/GB/T3627 | |||
System data | Weight of battery unit | 2.9T | 3T | 3T |
Dimensions of battery cabinet （W*H*D） | 1000*2450*1400mm | |||
Degree of protection | IP55 | |||
Operating temperature range | -30~55℃ | |||
Communication | Communication interfaces | RS485、CAN、LAN | ||
Communication protocols | ModBus TCP/ModBus RTU/CAN | |||
Data of AC | Rated power | 100KW | 125KW | |
Max power | 110KW | 150KW | ||
Nominal voltage | 400/480Vac | |||
Nominal frequency | 50/60Hz | |||
Power factor | -1～1 | |||
Output mode | 3W+N+PE | |||
