Technical advantage
•Modular structure, flexible combined cabinet, plug and play; High specific energy design，Save floor space 50%；IP54 protection rating，Meet various outdoor scenarios.
•3S fusion product，Integrated control；High-efficiency CTP technology，All in one integration technology； Separate management of AC and DC temperatures。
•The AB cabinet configuration is optional, and it can be freely controlled off-grid and grid-connected. Emergency power supply to improve power quality; Replace diesel generators and provide green power supply.
Battery data | Battery capacity | 250Ah | |
Nominal voltage at DC | 739.2V～950.4V | ||
Max Charge and Discharge power | 0.5C | ||
Battery capacity (BOL) at DC side | 211kWh | ||
Performance & safety | Nominal DC Charge and Discharge power | 95% | |
Cell type | LFP | ||
life span | 20years | ||
fire extinguishing system | Aerosol | ||
Temperature control mode | forced air cooling | ||
approval standards | UL9540/UL9540A/CE/IEC/KC/KBIA/GB/T 36276 | ||
System data | Weight of battery unit | 2.5T | |
Dimensions of battery cabinet（W*H*D） | 1600*2330*1200 | ||
Degree of protection | IP54 | ||
Operating temperature range | -20~55℃ | ||
Communication | Communication interfaces | RS485、CAN、LAN、4G | |
Communication protocols | ModBus TCP/ModBus RTU/CAN | ||
PCS | Grid connection on the AC side | Nominal output rating | 100kVA |
Nominal current | 150A | ||
Mac current | 160A | ||
Nominal grid voltage | 400Cac，3W+N+PE | ||
Nominal voltage | 50HZ | ||
Power factor | -1～+1 | ||
Total harmonic distortion of grid-connected current | <3%（Resistive balancing load） | ||
