Technical advantage
•Modular structure, flexible combined cabinet, plug and play; High specific energy design，Save floor space 50%；IP55 protection rating，Meet various outdoor scenarios.
•Five-level safety design, four-level protection guarantee and multi-dimensional early warning system，Comprehensively ensure system security。
•Refined management，System temperature difference≤3℃；
Battery capacity | 280Ah | 314Ah | 320Ah | |
Battery data | Nominal voltage at DC | 1311.2V | ||
Max Charge and Discharge power | 0.5CC/0.5CD | 0.5CC/ 0.5CD | 0.25CC/ 0.25CD | |
Battery capacity (BOL) at DC side | 372.7kWh | 417.9kWh | 425.9kWh | |
Performance & safety | Nominal DC Charge and Discharge power | 94% | ||
Battery type | LFP | |||
life span | 20years | |||
Fire extinguishing system | Aerosol + Water fire extinguishing system | |||
Temperature control mode | Liquid Cooling | |||
Approval standards | UL9540/CE/IEC | |||
System data | Weight of battery unit | 3.5T | 3.7T | 3.7T |
Dimensions of battery cabinet （W*H*D） | 1400*2350*1400mm | |||
Degree of protection | IP55 | |||
Operating temperature range | -30~55℃ | |||
Communication | Communication interfaces | RS485、CAN、LAN | ||
Communication protocols | ModBus TCP/ModBus RTU/CAN | |||
